JK 500
Multipurpose Shredder
Features and differences
The shredder has 2 cutting sizes to meet the specific needs of each herd.
The smaller cutting size is suitable for preparing feed for goat and sheep herds.
In this case, the equipment operates with 2 cutting systems, with 2 horizontal blades and 8 vertical blades.
The larger cutting size is ideal for preparing feed for cattle herds, in which case the vertical blades need to be removed by loosening the mounting screws.
Belt drive power transmission.
Body built of 4.25-mm-thick sheet metal.
Cutting blades made of special steel.
Two-pole switch that allows full isolation regardless of the position of the plug in the outlet.
Comes with: 4 pads and 1 manual kit.
For motels without motor, it also includes:
1 pulley and 2 belts.
Finish: Anti-corrosion treatment on all parts subject to oxidation and painted with polyester powder coating polymerized in a 220°C furnace, ensuring a longer lasting finish.
Warranty: 12 months (3 months legal warranty, 9 months special TRAPP warranty).
Indicated for the preparation of animal feed supplement.
Application:
It cuts palm (cactus), manioc branches, banana stems, sugarcane, macambira bromelia, “horse” forage watermelon, agave potatorum and other forages.
DATA SHEET
Motor: Electric
Output: 2hp
Voltage: 127/220V or 220/380V
Frequency: 60Hz
Type: One-phase
Machine speed: 3,600rpm
YIELD
Palm Chopper (cacti): up to 3,000kg/h
